Dual-Band 802.11ac Solution
ENL-Q6174A is an 802.11ac/a/b/g/n Dual-Band WiFi + Bluetooth M.2 card ( WiFi 5) based on Qualcomm Atheros QCA6174A chipset. It is Dual-Band AC on 2.4 and 5GHz and incorporates the latest Bluetooth 5.0. The slot type is M.2 2230. The download speed are 300Mbps on N networks and 867Mbps on AC network.
Secure Wireless Connection
Incorporated with advanced security encryption, such as WEP, WPA, WPA2, WPA3, WPS and 802.1x, it helps prevent user’s devices from malicious attacks.
Form Factor：M.2 A-E key 2230
Electrical Signal：Wi-Fi：PCIE / Bluetooth：USB
Data Stream
2 data streams with 2 HMF4 RF connectors
2.412 GHz ~ 2.480 GHz
5.150 GHz ~ 5.850 GHz
*Subject to local regulations
Deminsion (mm)
30.00(±0.15) x 22.00(±0.15) mm
Operating Voltage
DC 3.3V
Operating Temperature Range
Driver
Andriod/Linux/Windows
Chipset Offical Driver
Avaliable by requested.
Power – TX
Sensitivity – RX
Wi-Fi
802.11b @11Mbps : 18 dBm ± 2 dB
802.11g @54Mbps : 16 dBm ± 2 dB
802.11n @MCS7 : 15 dBm ± 2 dB
802.11a @54Mbps : 14 dBm ± 2 dB
802.11an @MCS7 :13.5 dBm ± 2 dB
802.11ac @MCS9 : 11 dBm ± 2 dB
802.11b:
Less than IEEE Standard -76dBm
802.11g / 802.11a:
Less than IEEE Standard -82dBm @ 6Mpbs
Less than IEEE Standard -65dBm @54Mbps
802.11n:
HT20:
Less than IEEE Standard -82dBm @ MCS0
Less than IEEE Standard -64dBm @ MCS7
HT40:
Less than IEEE Standard -79dBm @ MCS0
Less than IEEE Standard -61dBm @ MCS7
HT80:
Less than IEEE Standard -76dBm @ MCS0
Less than IEEE Standard -51dBm @ MCS9
0 ≤ Output Power ≤ +5; Class 1 Device
< 0.1% BER at -70dBm
- This module is with "World-Wide Certification" including FCC/CE/IC/TELEC/KCC...etc, please contact us for further information.
- Antenna Filings are available now.
