ENL-B4356(AP12356) is a single-die wireless local area network (WLAN) and Bluetooth combo solution to support2x2 multi-user multiple input with two spatial streams IEEE802.11ac/a/b/g/n WLAN standards and Bluetooth 5.0, designed to deliver superior integration of WLAN/Bluetooth and low energy technology.
ENL-B4356(AP12356) is dual band on 2.4GHz+5GHz and incorporates the latest Bluetooth 5.0. The download speed are 300Mbps on N networks and 867Mbps on AC network. ENL-B4356(AP12356) is integrates the Bluetooth transmission technology for voice and data transfers between devices in a short distance.ENL-B4356(AP12356) is designed properly for any wireless enabled devices with Half Mini PCIe slot.
Wi-Fi Protocol
IEEE 802.11 ac/a/b/g/n
Bluetooth version
Bluetooth 5.0
Interface
Form Factor : Half Size Mini PCIE card
Electrical Signal: Wi-Fi : PCIE / Bluetooth : USB
Data Stream
2 datat streams with 2 HMF4 RF connectors
Operating Frequency
2.400 GHz ~ 2.497 GHz (2.4GHz ISM Band)
4.900 GHz ~ 5.845 GHz (5.0GHz ISM Band)
*Subject to local regulations
Deminsion (mm)
29.85(±0.15) x 26.65(±0.15) x 2.64(±0.2) mm
Operating Voltage
DC 3.3V
Operating Temperature Range
-10~ 70°C
Driver
Andriod/Linux/Windows
Chipset Offical Driver
Avaliable by requested.
Power – TX
Sensitivity – RX
Wi-Fi
802.11b /11Mbps : 16 dBm ± 1.5 dB
802.11g /54Mbps : 15 dBm ± 1.5 dB
802.11n /MCS7 : 14 dBm ± 1.5 dB
802.11a /54Mbps : 13 dBm ± 1.5 dB
802.11an /MCS7 : 12 dBm ± 1.5 dB
802.11ac /MCS9 : 10 dBm ± 1.5 dB
802.11b /11Mbps : -84 dBm (Typical)
802.11g /54Mpbs : -73dbm (Typical)
802.11n /MCS7 : -68dbm (Typical)
802.11a /54Mbps : -69dBm (Typical)
802.11an /MCS7 : -67dBm (Typical)
802.11ac /MCS9 : -57 dBm (Typical)
7dbm typical (Class1.5)
@ BER=0.01% for π/4-DQPSK (2Mbps) : -78dbm
USA
EU Region
Japan
Canada
Above Certifications are under evaluation, please contact us for further information.
