The ENL-Q9882C is powered by Qualcomm Atheros QCA9882 radio chip and features 2×2 WiFi 5 technology for higher throughput performance, reliability and range. It is designed to meet the demanding performance requirements of critical embedded applications.
The ENL-Q9882C dramatically increase the overall throughput up to 867Mbps. Leveraging the revolutionary WiFi 5 technology, ENL-Q9882C sets a new benchmark in throughput and range, making it ideal for consumer and enterprise applications, such as point of sale, gaming machine and medical equipment.
Interface
Form Factor：Full Size Mini PCIE
Electrical Signal：Wi-Fi：PCIE
Data Stream
2 data streams with 2 UFL connector
Operating Frequency
2.412 GHz ~ 2.472 GHz
5.180 GHz ~ 5.825 GHz
*Subject to local regulations
Deminsion (mm)
30 x 51 x 3.2 (typical) mm
Operating Voltage
DC 3.3V
Operating Temperature Range
-20°C to 70°C
Chipset Offical Driver
Avaliable by requested.
Power – TX
Sensitivity – RX
Wi-Fi
11b@CCK 11Mbps：20dBm
11g@OFDM 54Mbps：18dBm
11gn@MCS7_HT20：16dBm
11gn@MCS7_HT40：16dBm
111a@OFDM 54Mbps：15dBm
11n/ac@VHT20@MCS8：13dBm
11n/ac@VHT40@MCS9：13dBm
11n/ac@VHT80@MCS9：13dBm
11b@CCK 11Mbps：-90dBm
11g@OFDM 54Mbps：-80dBm
11gn@MCS7_HT20：-77dBm
11gn@MCS7_HT40：-75dBm
111a@OFDM 54Mbps：-80dBm
11n/ac@VHT20@MCS8：-71dBm
11n/ac@VHT40@MCS9：-68dBm
11n/ac@VHT80@MCS9：-68dBm
USA
EU Region
Japan
Canada
Above Certifications are under evaluation, please contact us for further information.
