ENL-8852BASR

Name: ENL-8852BASR
Brand: ENL-8852BASR
SKU: 6252BA-SR
Availability: InStock

WiFi6 11ax Dual-band 2x2 11ax (SDIO) +Bluetooth 5.2 (UART) Stamp Combo Module

Model No.

6252BA-SR

Chipset Vendor

Realtek

Chipset part no.

RTL-8852BS-CG

Electrical Interface

WLAN @ SDIO /BT @ UART

OS support

Linux/Andriod

TAG BY

#SDIO #Commercail Grade #WiFi 6 #Solder mount module #Andriod #Linux #2*2 #General Purpose Wireless Modules

Enli Technology would like to announce a low-cost and low-power consumption module which has all of the Wi-Fi functionalities. It is a highly-integrated IEEE 802.11 a/b/g/n/ac/ax MAC/Baseband/RF WLAN single chip. For Wireless LAN operation. The integrated module provides SDIO interface for Wi-Fi.The module provides simple legacy and 20MHz/40MHz/80MHz co-existence mechanism to ensure backward and network compatibility.

The wireless module complies with IEEE 802.11 a/b/g/n/ac/ax 2x2 MIMO standard and the speed can achieve up to 1201Mbps with dual stream in 802.11ax. The integrated module provides SDIO interface for Wi-Fi, UART / PCM interface for Bluetooth.

This combo module is a total solution for a combination of Wi-Fi and Bluetooth V5.2 technologies. The module is specifically developed for all portable devices.

STANDARD

Wi-Fi Protocol

IEEE 802.11 ax/ac/a/b/g/n

Bluetooth version

Bluetooth 5.2

Interface

SDIO V1.0/V2.0/V3.0

RADIO

Data Stream

Operating Frequency

2.400 GHz ~ 2.4835 GHz (2.4G band)

5.15 GHz ~ 5.850 GHz (5G band)

Chipset

Realtek

SIZE

Deminsion (mm)

L x W : 15 x 13 (+0.3/-0.1) mm H: 2.35 (±0.2) mm

Wight (gw)

With shielding: 0.8g

ENVIROMENTAL

Operating Voltage

3.3V

Operating Temperature Range

Operating Temperature: -10ºC to 70ºC

Storage Temperature: -40ºC to 85ºC

SOFTWARE

Driver

Windows/Linux/Andriod

Chipset Offical Driver

Avaliable by requested.

POWER AND SENSITIVITY

Power – TX

Sensitivity – RX

Wi-Fi

2.4GHz

802.11b /11Mbps : 19dBm ± 2 dB

802.11g /54Mbps : 18dBm ± 2 dB

802.11n /MCS7 : 17dBm ± 2 dB

802.11ax HE20 MCS11: 13dBm ± 2 dB

802.11ax HE40 MCS11: 13dBm ± 2 dB

5GHz

802.11a /54Mbps: 18 dBm ± 2 dB

802.11n /MCS7: 17 dBm ± 2 dB

802.11ac vHT20 MCS8: 16 dBm ± 2 dB

802.11ac vHT40 MCS9: 15 dBm ± 2 dB

802.11ax HE20 MCS11: 13 dBm ± 2 dB

802.11ax HE40 MCS11: 13 dBm ± 2 dB

802.11ax HE80 MCS11: 13 dBm ± 2 dB

(2.4GHz)@10% PER:

802.11g, 20MHz: 6Mbps @ -90 dBm

802.11g, 20MHz: 54Mbps @ -71 dBm

802.11n, 20MHz: MCS=0 @ -90 dBm

802.11n, 20MHz: MCS=7 @ -69 dBm

802.11n, 40MHz: MCS=0 @ -87 dBm

802.11n,40MHz: MCS=7 @ -66 dBm

802.11ac,40MHz: MCS=0 @ -90 dBm

802.11ac,40MHz: MCS=8 @ -66 dBm

802.11ac,40MHz: MCS=0 @ -87 dBm

802.11ac,40MHz: MCS=9 @ -59 dBm

802.11ax,20MHz: MCS=0 @ -90 dBm:

802.11ax,20MHz: MCS=11 @ -60 dBm

802.11ax,20MHz: MCS=0 @ -87 dBm

802.11ax,20MHz: MCS=11 @ -57 dBm

(5GHz)@10% PER:

802.11a,6Mbps PER @ -90 dBm

802.11ac,54Mbps PER @ -71 dBm

802.11n,20MHz: MCS=0 PER @ -90 dBm

802.11n,20MHz: MCS=7 PER @ -69 dBm

802.11n,40MHz: MCS=0 @ -87 dBm

802.11n,40MHz: MCS=7 @ -66 dBm

802.11ac,40MHz: MCS=8 @ -66 dBm

802.11ac,40MHz: MCS=0 @ -87 dBm

802.11ac,40MHz: MCS=9 @ -59 dBm

802.11ax,20MHz: MCS=0 @ -90 dBm:

802.11ax,20MHz: MCS=11 @ -60 dBm

802.11ax,20MHz: MCS=0 @ -87 dBm

802.11ax,20MHz: MCS=11 @ -57 dBm

802.11n,20MHz: MCS=7 @ -69 dBm

Bluetooth

BDR, EDR, BLE: 5dBm

Sensitivity @ BER=0.1%:

GFSK (1Mbps) @-90dBm

Sensitivity @ BER=0.01%:

π/4-DQPSK (2Mbps)@-88dBm

8DPSK (3Mbps) @-85dBm

Sensitivity @ BER=30.8%:

LE (1Mbps) @-93dBm

2LE (2Mbps) @-90dBm

USA

EU Region

Japan

Canada

Above Certifications are under evaluation, please contact us for further information.
