ENL-Q9880C is a IEEE 802.11ac wireless adapter that operates in 2.4GHz and 5 GHz bands, available in PCIe mini card form factor. Featuring QCA9880 chipset, the ENL-Q9880C dramatically increases the overall throughput up to 1.3Gbps with 3 x 3 MIMO technique. Leveraging the revolutionary WiFi 5 technology, ENL-Q9880C sets a new benchmark in throughput and range, making it ideal for consumer and enterprise applications, such as video, voice and data transmission. The ENL-Q9880C is backward compatible with 802.11a/n and fully supports industry standards compliant security.
It supports 3T3R (3×3) technology, which runs up to 1.3Gbps (11ac VHT MCS9). The ENL-Q9880Csupports 20/40/80MHz and 256-QAM to maximize bandwidth efficiency. Adopting the latest 802.11ac solution, ENL-Q9880C is ideal for next-generation high throughput enterprise networking solution. Incorporated with advanced security encryption, such as 64/128-bits WEP, WPA, WPA2, and 802.1x, it helps prevent users’ devices from malicious attacks.
Wi-Fi Protocol
IEEE 802.11 ac/a/b/g/n
Interface
MiniPCI-Express 1.1 Standard
Data Stream
3 data streams with 3 UFL connector
Operating Frequency
2.412 ~ 2.472 GHz
5.180 ~ 5.825 GHz
Deminsion (mm)
50.95 x 30 x 3.2 mm
Operating Voltage
3.3V DC
Operating Temperature Range
-20ºC to 70ºC
Chipset Offical Driver
Avaliable by requested.
Power – TX
Sensitivity – RX
Wi-Fi
11b@CCK 11Mbps：20dBm
11g@OFDM 54Mbps：18dBm
11gn@MCS7_HT20：16dBm
11gn@MCS7_HT40：16dBm
111a@OFDM 54Mbps：15dBm
11n/ac@VHT20@MCS8：13dBm
11n/ac@VHT40@MCS9：13dBm
11n/ac@VHT80@MCS9：13dBm
11b@CCK 11Mbps：-90dBm
11g@OFDM 54Mbps：-80dBm
11gn@MCS7_HT20：-77dBm
11gn@MCS7_HT40：-75dBm
111a@OFDM 54Mbps：-80dBm
11n/ac@VHT20@MCS8：-71dBm
11n/ac@VHT40@MCS9：-68dBm
11n/ac@VHT80@MCS9：-68dBm
USA
EU Region
Japan
Canada
Above Certifications are under evaluation, please contact us for further information.
